Gigabyte X870E-Aorus-Master AM5 DDR5 Ses Glan HDMI/USB4 Sata3 USB3.2 ATX
Kategori
Marka
Garanti Süresi
24 Ay
Fiyat
23.150,00 TL + KDV
* 3.036,22 TL den başlayan taksitlerle!
27.780,00 TL
| STOK NO | 82165 |
| MARKA | GIGABYTE |
| GARANTİ SÜRESİ | 24 |
| EAN | 4719331864354 |
| İŞLEMCİ | AMD Socket AM5, support for: AMD Ryzen™ 9000 Series Processors/ AMD Ryzen™ 8000 Series Processors/ AMD Ryzen™ 7000 Series Processors |
| YONGA SETİ | X870E |
| BELLEK | Support for DDR5 8600(OC) / 8400(OC) / 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory Çift kanal bellek mimarisi ECC olmayan DIMM 1Rx8/2Rx8/1Rx16 hafıza modüllerini destekler Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTEs website for more information.) |
| DAHİLİ GRAFİK | Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz Support for DisplayPort 1.4 version and HDR. Integrated Graphics Processor - AMD Radeon™ Graphics support Maksimum 4096x2160 @ 60 Hz çözünürlüğü destekleyen 1 x HDMI bağlantı noktası * Support for HDMI 2.1 version, HDCP 2.3, and HDR. ** Support native HDMI 2.1 TMDS compatible ports. 1 x Front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz * Support for HDMI 1.4. (Graphics specifications may vary depending on CPU support.) |
| GENİŞLEME YUVALARI | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. ** The PCIEX16 slot shares bandwidth with the M2B_CPU and M2C_CPU connectors. The PCIEX16 slot operates at up to x8 mode when a device is installed in the M2B_CPU or M2C_CPU connector. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode Chipset 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4_1) 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4_2) |
| SES DESTEĞİ | Realtek® ALC1220 codec * Arka panel hat çıkışı jakı DSD sesini destekler. Support for DTS:X® Ultra HD Ses Desteği 2/4/5.1/7.1-kanal * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. S/PDIF Çıkış Desteği |
| LAN | Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| USB PORTLARI | CPU+ASMedia USB4® controller 2 x USB4® USB Type-C® ports on the back panel İşlemci 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel Yongaseti 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 4 x USB 3.2 Gen 1 ports available through the internal USB headers 6 x USB 2.0/1.1 yuvalar (2 yuva arka panelde, 4 yuva dahili USB bağlantı ile) Chipset+USB 3.2 Gen 1 Hub 4 x USB 3.2 Gen 1 ports on the back panel |
| DEPOLAMA ARAYÜZÜ | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs * The M2B_CPU and M2C_CPU connectors become unavailable when an AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 processor is used. 1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs 4 x SATA 6Gb/s konektörler RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors. RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| ARKA GİRİŞ/ÇIKIŞ PORTLARI | 1 x Q-Flash Plus button 1 x Clear CMOS düğmesi 1 x HDMI bağlantı noktası (Not:) 2 x USB4® USB Type-C® ports (DisplayPort) (Not:) 4 x USB 3.2 Gen 2 Type-A ports (red) 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 portlar 1 x RJ-45 bağlantı noktası 2 x antenna connectors (2T2R) 2 x ses jakı 1 x optik S / PDIF Çıkış konektörü (Not) Gerçek destek CPUya göre değişebilir. |
| DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI | 1 x 24-pin ATX ana güç konektörü 2 x 8 pinli ATX 12V güç konnektörleri 1 x CPU Fan konektörü 1 x CPU fan/water cooling pump header 4 x sistem fan konektörü 2 x sistem fan/sıvı soğutma pompa başlığı 4 x addressable RGB Gen2 LED strip headers 1 x RGB LED şerit başlığı 4 x M.2 Socket 3 connectors 4 x SATA 6Gb/s konnektörü 1 x ön panel başlığı 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support 2 x USB 3.2 Gen 1 headers 2 x USB 2.0 / 1.1 başlıkları 1 x noise detection header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only) TPM özeliği, bölgesel kuralların farklılığı nedeniyle opsiyonel olabilir 1 x HDMI bağlantı noktası (Not:) 1 x Power (Güç) Düğmesi 1 x Reset (Yeniden Başlatma) Düğmesi 1 x reset jumper 1 x Clear CMOS bağlayıcı teli 2 x sıcaklık sensör başlığı Voltaj Ölçüm Noktası (Not) Gerçek destek CPUya göre değişebilir. |
| İŞLETİM SİSTEMİ DESTEĞİ | Support for Windows 11 64-bit |
| FORM FAKTÖRÜ | ATX Form Faktör; 30.5cm x 24.4cm |
| BIOS | 1 x 256 Mbit flash Lisanslı AMI UEFI BIOS kullanımı PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Bellek Tipi | : | DDR5 |
| Chipset | : | X870 |
| Dahili Grafik | : | VAR |
| Form Faktörü | : | ATX |
| Marka | : | GIGABYTE |
| Socket Cinsi | : | AM5 |
